Tonfly 2X Mount Skydiving Camera Support – Insta360 X3, X4, X5 and X6

• Compatible headset: Tonfly 2X equipped with the Mount System
• Compatible cameras depending on the variant: Insta360 X3, Insta360 X4, Insta360 X5 and Insta360 X6
• Compatible system: Tonfly Mount System plate
• Mounting hole spacing: 41 mm (depth) × 23 mm (width)
• Camera mounting: standard 1/4-20 thread
• Tonfly plate attachment: 4 M4 screws

• Support manufactured using professional 3D printing, ready to assemble
• Approximate weight: approximately 18 g
• Compact design suitable for use on a skydiving helmet
• Camera mounting via standard 1/4-20 screw
• Direct mounting onto the Tonfly Mount System plate
• Design tested in real freefall conditions
• All necessary mounting hardware included

✔ Designed specifically for the Tonfly 2X Mount System
✔ Insta360 X3, X4, X5 and X6 compatible
✔ Physical product ready to assemble
✔ No need to replace the entire Tonfly system
✔ Standard 1/4-20 camera mount
✔ Compact and lightweight design
✔ Precise fit on the Tonfly plate
✔ Tested in real freefall conditions
✔ Made and inspected in my workshop in France
✔ Screws included

• Material : PETG or PETG-Carbon depending on the chosen variant
• Manufacturing: Professional 3D printing in my workshop in France
• Quality control: Each item is checked before shipment
• Product made to order: Each stand is made especially for you.
• Manufacturing time: Please allow 3 to 4 days before shipment.

• PETG : resistance suitable for shocks and temperature variations, recommended for the majority of uses.
• PETG-Carbon : more rigid, with a matte black finish, particularly suitable for intensive use.

1. Position the Nayoki bracket on your Tonfly Mount System plate.
2. Secure it using the M4 screws provided.
3. Attach your Insta360 to the stand using the supplied 1/4-20 screw.
4. Carefully check the alignment and tightness of the assembly.
5. Test the setup in a controlled environment before any use in jumping.

Insta360 X5: The charging port is located under the camera and is inaccessible once the mount is installed. To maintain a rigid and sturdy base, the mount is intentionally designed without an opening under the camera.

To avoid repeated disassembly, the use of a external battery charger is recommended for charging the batteries of the Insta360 X5.

Insta360 X6: A dedicated variant of the mount allows the Insta360 X6 to be installed on the Tonfly 2X Mount System.

The mount was designed for use on a skydiving helmet and tested in real freefall conditions.

Before each use:

• check the overall condition of the support; ;
• check that the screws are tight; ;
• ensure that no part of the assembly presents a risk of unwanted snagging; ;
• check that the camera is securely attached; ;
• Have your configuration validated by the technical manager of your center when necessary.

The assembly and use of this support remain the responsibility of the user and the technical manager of their jump center.

Are the screws included?
Yes. The screws needed to attach the bracket to the Tonfly plate and install the Insta360 are included.

Which helmet can I install this mount on?
This version is designed for the Tonfly 2X equipped with the Mount System.

Which cameras are compatible?
The support exists in variants dedicated to the Insta360 X3, X4, X5 and X6.

Do I need to replace my Tonfly license plate?
No. The bracket is designed to attach directly to the existing Tonfly Mount System plate.

Can an Insta360 X5 be recharged while it is mounted?
The charging port located on the underside of the X5 is inaccessible once the camera is installed. An external battery charger eliminates the need to frequently disassemble the camera.

• Insta360 X5 External Battery Charger To recharge the batteries without disassembling the camera: See on Amazon
• Speedometer and altitude counter Free to overlay your telemetry data into your jump videos: access the tool

• 360° POV + exterior view with this mount

Designed, manufactured and tested by Connec7e under the brand Nayoki, in my French workshop dedicated to skydiving, 3D printing and functional design.
